DA Helical Gear High Precision Planetary Gearbox

DA Series High Precisions Helical Planetary Gear Box is an impressive assortment of servo grade planetary gearbox for our different inline and right-angle series. Providing the ultimate flexibility for our customers.

Back INQUIRY
Go TO Top

Features

- High Precision Helical Gear -

 The planetary gear and sun gear are manufactured from high quality Ni-Cr-Mo alloy steel. Precision machined and carburized, then for precision tooth grinding or skiving assures gears high precision.

- Modular Deisgn of Motor Connection Plate -

The special modular design of motor connection plate is suitable for any brand and any type of servomotor. Manufactured from aluminum alloy, its surface is anodized treated for upgrading environmental-resistant and corrosion-resistant capability.

- Single-piece Gearbox & Advanced Surface Treatment -

The gearbox and internal gear ring are single price design and constructed, which is manufactured from Cr-Mo alloy steel, and tempered for high torque output. Gearbox surface is anti-corrosive treated for upgrading environmental resistant and corrosionresistant capability.

- Modular Input Shaft -

Modular input shaft design and motor shaft are coupled through a dynamic balanced collar clamping mechanism to ensure connection concentricity and zero slip power transmission at high speed.

- Integrated Planetary Arm Bracket -

The planetary arm bracket and the output shaft are single piece design constructed to increase torsional rigidity and accuracy. The entire structure is one-time machined for controlling accuracy in the specified tolerance.

Go TO Top

Technical

Information





Specification

Ratio (Stage)

DA060

DA090

DA120

DA150

Instantaneous Max. Output Torque

3/9/10/12/21/30

111

345

624

1350

4/15/16/20/25/40

141

480

804

1950

7/28/35/70/100

135

450

780

1650

5/50

141

450

780

1800

Defined Output Torque

T2N (Nm)

3/9/10/12/21/30

37

115

208

450

4/15/16/20/25/40

47

160

268

650

7/28/35/70/100

45

150

260

550

5/50

47

150

260

600

Reduction Ratio

L1: 1 Stage

3 / 4 / 5 / 7 / 10

L2: 2 Stage

9 / 12 / 15 / 16 / 20 / 21 / 25 / 28 / 30 / 35 / 40 / 49 / 50 / 70

L3: 3 Stage

100 / 200 / 250

Defined Input Rotational Speed

n1N (rpm)

L1, L2, L3

5000

4000

4000

3000

Backlash (arcmin)

3~10 (L1)

P0≤1,  P1≤3,  P2≤5

12~100 (L2)

P0≤3,  P1≤5,  P2≤7

Torsional Rigidity (Nm/arcmin)

3~100

 (L1,L2)

6.5

14

27

48

Allowable Radial Force

F2rB2 (N)

3~100

 (L1,L2)

1600

4000

7000

10000

Allowable Axial Force

F2aB2 (N)

3~100

 (L1,L2)

800

2000

3500

5000

Full Load Efficiency

%

3~10 (L1)

≥97

12~100 (L2)

≥94

Service Life Lh2 (hrs)

3~100 (L1,L2)

20000*

Weight (kgs)

3~10 (L1)

1.3

3.9

7.0

18.0

12~100 (L2)

1.8

5.1

9.2

22.5

Noise (db)



58

60

63

65

Temperature °C



(  -15°C ~ +90°C  )

Protection Rank



IP64

Lubricating Oil



Synthetic Lubricant ISO VG220

Moment Of Inertia J1 (kg.cm2)

Stage

Ratio





L1

3

0.180

1.39

3.05

16.19

4

0.121

0.92

2.02

10.11

5

0.099

0.77

1.68

7.68

7

0.089

0.70

1.51

7.05

10

0.077

0.64

1.37

6.37

L2

9

0.160

1.22

2.78

14.65

12

0.155

1.19

2.71

14.63

15

0.150

1.17

2.65

14.58

16

0.107

0.83

1.86

9.11

20

0.091

0.73

1.59

8.11

21

0.149

1.16

2.53

13.44

25

0.091

0.73

1.58

7.08

28

0.087

0.69

1.48

6.77

30

0.077

0.62

1.35

6.34

35

0.084

0.67

1.44

6.65

40

0.077

0.64

1.37

6.37

49

0.084

0.67

1.44

6.65

50

0.077

0.64

1.35

6.18

70

0.076

0.62

1.33

6.12

L3

100

0.091

0.72

1.56

7.01


※For 3 stage technical data, contact Varitron® or your sales personal.

※Use larger model when large moment of inertia is needed.

※Continuous operating will reduce service life.










Go TO Top

Designation

j

Model

DA: Helical Gear High Precision Planetary Gearbox

DM:Precision Planetary Gearbox

DF:Precision Flange Type Planetary Gearbox

DH:Standard Precision Planetary Gearbox

DL:Standard Precision Planetary Gearbox

DN:High R-A Load Standard Precision Planetary Gearbox

RAM-S:Precision Shaft Output Spiral Bevel Gearbox

RAM-SS:Precision Double Shaft Spiral Bevel Gearbox

RAM-H:Precision Hollow Shaft Spiral Bevel Gearbox

RAM-D: Precision Clamping Shaft Spiral Bevel Gearbox

RAM-F: Precision Flange Spiral Bevel Gearbox

RAH-S: Standard Precision Shaft Output Spiral Bevel Gearbox

RAH-SS:Standard Precision Double Shaft Spiral Bevel Gearbox

RAH-H:Standard Precision Hollow Shaft Spiral Bevel Gearbox

RAH-D:Standard Precision Clamping Shaft Spiral Bevel Gearbox

RAH-F: Standard PrecisionFlange Spiral Bevel Gearbox



k

Frame Size

DA060-P0-L1 = Backlash ≤1 ,  DA060-P0-L2 = Backlash ≤3

DA060-P1-L1 = Bachlash ≤3 ,  DA060-P1-L2 = Backlash ≤5

DA060-P2-L1 = Backlash ≤5,   DA060-P2-L2 = Backlash ≤7



DA090-P0-L1 = Backlash ≤1 ,  DA090-P0-L2 = Backlash ≤3

DA090-P1-L1 = Bachlash ≤3 ,  DA090-P1-L2 = Backlash ≤5

DA090-P2-L1 = Backlash ≤5,   DA090-P2-L2 = Backlash ≤7



DA120-P0-L1 = Backlash ≤1 ,  DA120-P0-L2 = Backlash ≤3

DA120-P1-L1 = Bachlash ≤3 ,  DA120-P1-L2 = Backlash ≤5

DA120-P2-L1 = Backlash ≤5,   DA120-P2-L2 = Backlash ≤7



DA150-P0-L1 = Backlash ≤1 ,  DA150-P0-L2 = Backlash ≤3

DA150-P1-L1 = Bachlash ≤3 ,  DA150-P1-L2 = Backlash ≤5

DA150-P2-L1 = Backlash ≤5,   DA150-P2-L2 = Backlash ≤7



l

Stage

L1, L2, L3

m

Ratio

L1: 3 / 4 / 5 / 7 / 10

L2: 9 / 12 / 15 / 16 / 20 / 21 / 25 / 28 / 30 / 40 / 49 / 50 / 70

L3: 36 / 45 / 60 / 75 / 80 / 150 / 200 / 300 / 400 / 500 / 700 / 1000

n

Motor Shaft Diameter

(S)

Customized according to customer requirement.

o

Motor Pilot Diameter

(B)

Customized according to customer requirement.

p

Motor Guide Depth

(P)

Customized according to customer requirement.

q

Installing Screw P.C.D

(M)

Customized according to customer requirement.

r

Installing Screw Size

(A)

Customized according to customer requirement.




s



Motor Shaft Length

(R)

Customized according to customer requirement.
Go TO Top
